210kg Payload 2688mm Reaching Distance China Handling Drilling Robotic Arm EVS

QJAR heavy-duty and big-payload robotic arm. It’s with large work space and high reliability….
Item No.: QJR210-1
Payment: T/T
Product Origin: China
Shipping Port: Shanghai or designated port
Lead Time: 15-30 working days
Share
Categorii: , ,
Solicita Oferta

Descriere

  • Payload 210kg, reach distance of 2.68 meters, the design is highly compact.
  • Large workspace, high running speed, high repeat positioning accuracy, suitable for welding, palletizing, loading and unloading, handling, polishing, assembly and other wide range of applications.

Informații suplimentare

Model:

QJR210-1
Axis Number

6
Payload

210kg
Repeat Positioning

±0.2mm
Max Armspan

2688mm
Motion Range

J1 ±165º J2 ﹢85º,﹣50º J3 ﹢75º,﹣160º J4 ±360º J5 ±120º J6 ±360º
Max Speed

J1 100º/s J2 80º/s J3 95º/s J4 130º/s J5 120º/s J6 200º/s
Allowable Torque

J4 1200N.m J5 1200N.m J6 650N.m
Inertia Moment

J4 84kg.m² J5 84kg.m² J6 55kg.m²
Robot Body Weight

1257kg
Power Capacity

30.6kVA
Cabinet Size

650*750*1150mm
Cabinet Weight

140kg
Source

Three-phase four-wire
Installing Form

Ground
